Nikon D850 Camera Modified for Monochrome Visible Light.

Note: Camera will shoot about 1 stop faster than a stock camera.  You should use Exposure Compensation (EC) to adjust.  Check you histograms when shooting to make sure you are exposing correctly.  Shooting in Live View works very well since camera using the image sensor to set exposure and focus.





Image Sensor
Sensor Type:	CMOS
Sensor Manufacturer:	Sony
Effective Megapixels:	45.7
Sensor Format:	35mm
Sensor size:	858.01mm2 (35.90mm x 23.90mm)
Approximate Pixel Pitch:	4.35 microns
Focal Length Multiplier:	1.0x
Aspect Ratio:	3:2
Color Filter Type:	RGBG
Anti Aliasing Filter:	None
Self-Cleaning:	Yes
Sensor shift image stabilization:	No
On-Sensor Phase Detect:	No
DxO Sensor Score:	100
DxO Color Depth Score (bits):	26.4
DxO Dynamic Range Score (evs):	14.8
DxO Maximum Effective ISO Score (iso):	2,660
Image Capture
Image Resolution:	8256 x 5504 (45.4 MP, 3:2), 6192 x 4128 (25.6 MP, 3:2), 4128 x 2752 (11.4 MP, 3:2), 6880 x 4584 (31.5 MP, 3:2), 5152 x 3432 (17.7 MP, 3:2), 3440 x 2288 (7.9 MP, 3:2), 6880 x 5504 (37.9 MP, 5:4), 5152 x 4120 (21.2 MP, 5:4), 3440 x 2752 (9.5 MP, 5:4), 5504 x 5504 (30.3 MP, 1:1), 4128 x 4128 (17.0 MP, 1:1), 2752 x 2750 (7.6 MP, 1:1)
Image File Format:	JPEG (EXIF 2.31), NEF (RAW): 12 or 14 bit, lossless compressed, compressed, or uncompressed; large, medium, and small available (medium and small images are recorded at a bit depth of 12 bits using lossless compression); TIFF
Continuous-mode frames/second:	7.1
Video Capture
Can take movies:	Yes
Movie Resolution:	3840x2160 (30p/​25p) 1920x1080 (60p/​50p/​30p/​25p/​24p) 1280x720 (60p/​50p) 1920x1080 (120p/​100p)
Movie File Format:	MOV/MP4 (H.265/MPEG-4 AVC, Linear PCM/AAC audio)
Composite Video Out:	No
NTSC/PAL Switchable Video:	n/a
Video Usable as Viewfinder:	n/a
HD Video Out:	Yes
HD Video Connection:	HDMI
Lens & Optics
Lens Mount:	Nikon F
Lens:	n/a
Focal Length (35mm equivalent):
Focal Length (actual):
Zoom Ratio:
Aperture Range:
Integrated ND Filter:
Normal Focus Range:
Macro Focus Range:
Filter Thread:	n/a
Thread Type:	n/a
Optical Image Stabilization:	No
Digital Zoom:	Yes
Digital Zoom Values:	1.2x, 1.5x (DX), 5:4, 1:1 crop modes
Auto Focus
Auto Focus:	Yes
Auto Focus Type:	Nikon Advanced Multi-CAM 20K autofocus sensor module with TTL phase detection and fine-tuning: 153 focus points (including 99 cross-type sensors and 15 sensors that support f/8), of which 55 (35 cross-type sensors and 9 f/8 sensors) are available for selection; Contrast-detect AF in Live View mode
Auto Focus Assist Light?	No
Manual Focus:	Yes
Viewfinder
Viewfinder:	Optical / LCD
Viewfinder Type:	SLR; eye-level pentaprism, 100% coverage, 0.75x magnification, 17mm eyepoint, -3 to +1 diopter
Focus Peaking:	Yes
EVF Resolution:	n/a
Viewfinder Magnification (35mm equivalent):	0.75x
Viewfinder Magnification (nominal/claimed):	0.75x
Display
Eye-level Viewfinder:	Yes
Rear Display:	Yes
Rear Display Size (inches):	3.2
Rear Display Resolution:	2,359,000 dots (589,750 px)
Touchscreen:	Yes
Articulating Screen:	Yes
Tilt Swivel Screen:	No
Selfie Screen:	No
Max Playback Zoom:	32.0x
Top Deck Display:	Yes
Exposure
Maximum ISO (native):	25600
Minimum ISO (native):	64
ISO Settings:	Auto, 64 - 25,600 in 1/3, 1/2 or 1EV steps, plus down to 32 in Lo-1, up to 102,400 in Hi-2
Auto ISO Mode:	Yes
White Balance Settings:	Auto (3), Incandescent, Fluorescent (7), Direct Sunlight, Flash, Cloudy, Shade, Preset Manual (6) (Spot WB available in Live View), Color Temperature (2,500K-10,000K); Fine-tuning available for all options.
Shutter Speed Range:	1/8000 - 30 sec
Bulb Mode:	Yes
Exposure Compensation:	+/- 5.0EV in 0.3EV steps
Metering Modes:	180K-pixel 3D Color Matrix Metering III, Center-weighted (weight of 75% given to 12-mm circle in center of frame; diameter of circle can be changed to 8, 15 or 20 mm, or weighting can be based on average of entire frame), Spot (4mm circle or about 1.5% frame, centered on selected focus area), Highlight-weighted: Available with type G, E, and D lenses
Program Auto Exposure:	Yes
Aperture Priority:	Yes
Shutter Priority:	Yes
Full Manual Exposure:	Yes
Creative Exposure Modes:	None
Self Timer:	2/5/10/20 seconds
Time Lapse (intervalometer):	Yes
High Resolution Composite:	No
Flash
Built-in Flash:	No
Flash Modes:	n/a
Flash Guide Number (ISO 100):	n/a
Flash Range Description:	n/a
Max Flash Sync:	1/250
Flash Exposure Compensation:	-3 to +1 EV in 0.3EV steps
External Flash Connection:	ISO-type hot-shoe, PC Sync terminal
Built-In Wireless Flash Control:	No
Image Storage
Usable Memory Types:	XQD / SD / SDHC / SDXC
UHS Support:	UHS-II
Other Memory:	1 SD UHS-II slot, 1 XQD slot
Dual Card Slots:	Yes
RAW Capture Support:	Yes
Uncompressed Format:	NEF (RAW): 12 or 14 bit, lossless compressed, compressed, or uncompressed; large, medium, and small available (medium and small images are recorded at a bit depth of 12 bits using lossless compression); TIFF
Movie File Format:	MOV/MP4 (H.265/MPEG-4 AVC, Linear PCM/AAC audio)
Included Memory:	No memory included
Included Memory Type:
Connectivity
Built-In Wi-Fi:	Yes
NFC:	No
Bluetooth:	Yes
Built-In GPS:	No
Microphone Jack:	Yes
Headphone Jack:	Yes
External Connections:	USB 3.0 Super Speed,Bluetooth,WiFi
PictBridge Compliant:	Yes
DPOF Compliant:	Yes
Remote Control:	Yes
Remote Control Type:	Optional wired or wireless
Connections (extended):	Mini HDMI (Type C), USB 3.0 Micro-B, 10-pin Expansion Terminal (GP-1 GPS compatible), Stereo Mic Mini Jack (3.5mm), Stereo Audio Out (3.5mm)
Performance Timing
Cycle time for JPEG shooting in single shot mode (seconds per frame, max resolution):	<0.3
Cycle time for RAW shooting in single shot mode (seconds per frame):
Buffer size for RAW shooting in single shot mode (frames):
Cycle time for RAW+JPEG shooting in single shot mode (seconds per shot):	<0.3
Camera penalizes early shutter press?	No
JPEG shooting speed in burst mode (fps, max resolution):	7.1
Buffer size for JPEG shooting in burst mode (frames, max resolution):	200
RAW shooting speed in burst mode (fps):	7.1
Buffer size for RAW shooting in burst mode (frames):	200
RAW+JPEG shooting speed in burst mode (fps):	7.1
Buffer Size for RAW+JPEG shooting in burst mode (frames):	53
Shutter lag (full AF, wide/mid):	0.08 seconds
Shutter lag (full AF, tele):
Shutter lag (full AF, live view - DSLR):	0.73 seconds
Shutter lag (prefocused, live view - DSLR):	0.145 seconds
Shutter Lag (manual focus):	0.052 seconds
Shutter lag (full AF, with flash):
Shutter Lag (prefocused):	0.046 seconds
Shutter Lag (notes):
Startup Time:	0.2 seconds
Play -> Record Time:	0.1 seconds
Flash cycle time, full power:
Power
Battery Life, Stills (CIPA Rating Monitor/Live View):
Battery Life, Still (CIPA Rating OVF/EVF):	1840 shots
Battery Life, Video:	70 minutes
Battery Form Factor:	Proprietary
Usable Battery Types:	EN-EL15a Lithium-ion rechargeable or MB-D18 battery grip
Batteries Included:	1 x Proprietary EN-EL15a Lithium-ion rechargeable
Battery Charger Included (dedicated charger or AC/USB adapter):	Yes
Dedicated Battery Charger Included:	Yes
Internal Charging Supported:	No
