SKU XNiteUSBDual4MP-VIS-IRCatalog ID 15989
$546.25
USD · per unit
Availability on request
Confirm current pricing and availability before ordering.
Saved cart · Quotes and order drafts available. No payment is collected.
2 x 2 Megapixel 1920 x 1080 Camera
2 Megapixel Visible Light Camera
2 Megapixel Infrared (IR) Light Camera with 850nm +/- 10nm Bandpass Filter
850nm IR LED Illuminators
2 USB Connections. One for each camera.
Housing and Mounting Bracket.
M12 3.6mm Lens 70 Degree No Distortion Lens
Other M12 Lenses May Be Used
Windows, Mac, Linux, Android, Wince Compatible
|
Model |
XNiteUSBDual2MP |
|
Sensor |
OV2710 x 2 |
|
Sensor Size |
1/2.7 inch x 2 |
|
Pixel Size |
3μm x 3μm |
|
image area |
5856 μm x 3276 μm x 2 |
|
Max. Resolution |
FULL HD 1920(H)X1080(V) x 2 |
|
Compression format |
MJPEG / YUV2（YUYV） |
|
Resolution & frame |
320X240 QVGA MJPEG @30fps/ 352X288 CIF MJPEG @30fps 640X480 VGA MJPEG@30fps/ 800X600 SVGA MJPEG@30fps 1024X768 XGA MJPEG@30fps/ 1280X720 HD MJPEG@30fps 1280X1024 SXGA MJPEG@30fps/ 1920X1080 FHD MJPEG@30fps |
|
Special function |
Lens correction/ Defective pixel correction/ Black sun cancellation |
|
Mini illumination |
0. 05lux |
|
Shutter Type |
Electronic rolling shutter / Frame exposure |
|
USB protocol |
USB2.0 HS/FS |
|
Connecting Port type |
USB2.0 High Speed |
|
OTG protocol |
USB2.0 OTG |
|
Free Drive Protocol |
USB Video Class（UVC） |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Adjustable parameters |
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, |
|
Lens Parameter |
Standard 3.6 mm, optional/2.5/2.8/3.6/6mm/FOV(D)187 Degree/170 Degree |
|
Night vision |
Support, need to equipped IR sensor 850nm or 940nm lens and IR LED Board |
|
LED board power connector |
Support 2P-2.0mm socket |
|
Power supply |
USB BUS POWER 4P-2.0mm socket |
|
Power supply |
DC5V |
|
Operating Voltage |
120mA~220mA |
|
Working current |
0～60℃ |
|
Working temperature |
-20～75℃ |
|
Board size /Weight |
38X38mm（Compatible 32X32mm）/ about 30g |
|
Cable |
Standard 1M / optional 2M,3M,5M |
|
Operating system request |
WinXP/Vista/Win7/Win8 Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC |
Recorded values and their sources are listed below. Confirm requirements against manufacturer documentation.
| Attribute | Value | Source |
|---|---|---|
| Spectral family | Infrared, Visible | Derived from legacy name / SKU / category |
Recorded dimensions may include packaging.
