USB 2.0 48 Megapixel Color Camera Full Spectrum UV-VIS-IR

SKU XNiteUSB48M-CCatalog ID 16190

$850.00

USD · per unit

Availability on request

Confirm current pricing and availability before ordering.

Saved cart · Quotes and order drafts available. No payment is collected.

Overview

USB 2.0 48 Megapixel Camera

No Sensor Coverglass

UV-VIS-IR Full Spectrum

Model	XNiteUSB48M-M
Sensor	SONY IMX586
Lens Size	1/3.2inch
Pixel Size	1.4um
image area	6.18mm x 5.85mm
Max. Resolution	3264(H) X 2448(V) 8Megapixel
Compression format	MJPEG / YUV2（YUYV）
Resolution & frame	8000x6000 @ 5fps MJPEG / 4000x3000 @ 12fps MJPEG 3840x2160 @ 30fps MJPEG / 1920x1080 @ 30fps MJPEG 1280x720 @ 30fps MJPEG 19201080 @5fps YUY2 / 800600 @25fps YUY2 640*480 @20fps YUY2
S/N Ratio	37dB
Dynamic Range	82dB
Sensitivity	1.4V/lux-sec@550nm
Mini illumination	0.3lux
Shutter Type	Electronic rolling shutter / Frame exposure
Connecting Port type	USB2.0 High Speed
Free Drive Protocol	USB Video Class（UVC）
OTG protocol	USB2.0 OTG
AEC	Support
AEB	Support
AGC	Support
Button camera	Support
Adjustable parameters	Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, Gain, White balance, Backlight Contrast, Exposure
Lens Parameter	4.0mm
LED board control interface	Support 2P-1.25mm socket
LED board power connector	Support 2P-2.0mm socket
Power supply	USB BUS POWER 4P-2.0mm socket
Operating Voltage	DC5V
Working current	550mA~650mA
Working temperature	-10～70℃
Storage temperature	-20～85℃
Board size	38X38mm（compatible 32X32mm）
Operating system request	WinXP/Vista/Win7/Win8 Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC

Recorded values and their sources are listed below. Confirm requirements against manufacturer documentation.

Attribute	Value	Source
Resolution	48 MP	Derived from legacy name / SKU / category
Spectral family	Full Spectrum	Derived from legacy name / SKU / category

Recorded dimensions may include packaging.

MAXMAX / CATALOG

Overview

USB 2.0 48 Megapixel Camera

No Sensor Coverglass

UV-VIS-IR Full Spectrum

Model	XNiteUSB48M-M
Sensor	SONY IMX586
Lens Size	1/3.2inch
Pixel Size	1.4um
image area	6.18mm x 5.85mm
Max. Resolution	3264(H) X 2448(V) 8Megapixel
Compression format	MJPEG / YUV2（YUYV）
Resolution & frame	8000x6000 @ 5fps MJPEG / 4000x3000 @ 12fps MJPEG 3840x2160 @ 30fps MJPEG / 1920x1080 @ 30fps MJPEG 1280x720 @ 30fps MJPEG 19201080 @5fps YUY2 / 800600 @25fps YUY2 640*480 @20fps YUY2
S/N Ratio	37dB
Dynamic Range	82dB
Sensitivity	1.4V/lux-sec@550nm
Mini illumination	0.3lux
Shutter Type	Electronic rolling shutter / Frame exposure
Connecting Port type	USB2.0 High Speed
Free Drive Protocol	USB Video Class（UVC）
OTG protocol	USB2.0 OTG
AEC	Support
AEB	Support
AGC	Support
Button camera	Support
Adjustable parameters	Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, Gain, White balance, Backlight Contrast, Exposure
Lens Parameter	4.0mm
LED board control interface	Support 2P-1.25mm socket
LED board power connector	Support 2P-2.0mm socket
Power supply	USB BUS POWER 4P-2.0mm socket
Operating Voltage	DC5V
Working current	550mA~650mA
Working temperature	-10～70℃
Storage temperature	-20～85℃
Board size	38X38mm（compatible 32X32mm）
Operating system request	WinXP/Vista/Win7/Win8 Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC

Attribute

Value

Source

Resolution

48 MP

Derived from legacy name / SKU / category

Spectral family

Full Spectrum

Derived from legacy name / SKU / category
